Designed to complement our XS range, the FlatCap XS is a dual-rail, dual-output power supply that powers not just one, but two Naim Audio components if required. For example, an XS Series owner could add a FlatCap XS to enhance the performance of both a CD5 XS and a NAC 152 XS, and so enjoy all the improvements to clarity, dynamics and timing you’d expect from any Naim Audio power supply upgrade. It’s a logical, high-value and highly effective upgrade path – just as you’d expect from Naim Audio.
Features
Dual-rail power supply with four 24V power outputs
Four low-noise regulators
Black-anodised chassis with brushed front panel plus anti-vibration feet
Technology & Craft
The FlatCap XS transformer has two separate secondary windings to isolate each of the dual supplies from the other. It includes four Naim Audio-tested and selected low-noise regulators to achieve its exceptional performance.
Finish
Case
Black powder coated
Front
Brushed and black anodised
Outputs
Power Outputs
4 x 24V
Physical
Shipping Weight
7.6 kg
Shipping Dimensions
200 x 590 x 500 mm
Weight
5.5 kg
Dimensions (HxWxD)
70 x 432 x 301 mm
Power
Mains Supply
100V, 115V, 230V; 50 or 60Hz
Supplied with
Supplied with
SNAIC
Upgrades
Other
Power-Line Lite mains cable (UK denominations only)
