Technical specifications

Output – 0.7 mV
Frequency range – 10-25.000 Hz
Tracking ability at 315Hz at recommended tracking force *) – 70 µm
Compliance, dynamic, lateral – 30 µm/mN
Stylus type – Elliptical
Stylus tip radius – r/R 6/18 µm
Tracking force range – 1.25-1.75 g (12.5-17.5 mN)
Tracking force, recommended – 1.5 g (15 mN)
Tracking angle – 20°
Stylus colour – Black
*) Typical value
