Pro-Ject Dac Box E DAC

Digital-to-analogue converter

DAC Box E: Pure listening pleasure for digital sources at an absolute bargain price!

The entry level DAC Box E is an excellent D/A converter for digital sound sources using optical and coaxial connections. Despite the low price, it sounds outstanding and supports HD music data up to 24/192kHz. DAC Box E uses high quality components like precision D/A converter chips and a low noise output stage. It will act as a perfect upgrade for any digital stereo audio source, especially for best-buy CD-players, Bluray or DVD players with CD playback, set-top boxes etc!

The whole audio circuitry design is perfectly linear with low output impedance to avoid any negative interference with cables or pre-amps. Its class-leading audio performance makes DAC Box E an outstanding low-cost audio bargain!

Features

  • 24bit / 192kHz D/A conversion
  • Co-axial (RCA) & optical (Toslink) S/PDIF input
  • SMD circuitry
  • Special low noise components
  • Internal metal shielding
  • Small size allows installation close to source
  • Gold plated RCA connection sockets
  • Outboard power supply included
  • Black or White casing

Technical Specifications

Line-level output 1 pair RCA/phono sockets
Output voltage 0.7 Vrms
Digital inputs 1x coaxial (S/PDIF), 1x optical (TOSlink®)
D/A converter Texas Instruments TLV320DAC23 Cirrus Logic CS4344. 24Bit/192kHz
Supported audio format PCM (LPCM) (Stereo only, no support for multi-channel formats)
Sampling rates Optical and coaxial input 44.1 kHz, 48kHz, 96 kHz and 192 kHz (coaxial only)
Outboard power supply 18 V / 500 mA DC; 220 – 240V, 50Hz
Power consumption 200 mA DC, <1W in standby
Dimensions W x H x D (D with sockets) 120 x 32 x 100 (106) mm
Weight 250 g without power supply
