Digital to Analogue Converter

Thanks to a Wolfson 24-bit DAC, a 24-bit/96kHz driverless USB Audio 1.0 input and S/PDIF and TosLink digital inputs, the DacMagic 100 takes the sound from your computer, iPod, TV and other digital devices and adds detail, depth and added clarity to give you a true audio experience.

Generally the digital to analogue converter found in typical digital devices is pretty poor and won’t extract the truest quality of audio from your sources. The DacMagic 100 works by taking a direct digital audio signal from your device to bypass its soundcard or DAC. It then digitally processes the audio signal using their custom designed technology, dramatically improving sound quality and reducing distortion. This results in greater detail, sparkling clarity and a deeper scale to all of your audio.

DacMagic 100 is very flexible and supports virtually all digital file formats including the very highest quality 24-bit studio master or lossless quality audio files stored on your computer. With three different digital connectivity options and the ability to connect four devices concurrently, DacMagic 100 is a true digital music enhancement hub. Set-up is totally intuitive, allowing you to begin enjoying better quality audio in minutes.

DIGITAL TO ANALOGUE CONVERTER: Wolfson WM8742 24-bit DAC
FREQUENCY RESPONSE: 20Hz to 20kHz (±0.1dB)
THD @ 1KHZ 0DBFS: <0.0025% 24-bit
THD @ 1KHZ -10DBFS: <0.0025% 24-bit
THD @ 20KHZ 0DBFS: <0.0025%
SIGNAL TO NOISE RATIO: -113dBr
TOTAL CORRELATED JITTER: <130pS
CROSSTALK @ 1KHZ : < -130dB
CROSSTALK @ 20KHZ: < -112dB
OUTPUT IMPEDANCE: <50ohms
MAX. OUTPUT LEVEL (UNBALANCED): 2.3V rms
DIGITAL INPUT WORD WIDTHS SUPPORTED: 16-24bit
DIGITAL INPUT SAMPLING FREQUENCIES SUPPORTED: 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 192kHz
MAX. POWER CONSUMPTION: 5W
COLOUR: Black or silver
DIMENSIONS (WXHXD): 106 x 46 x 130mm (4.1 x 1.8 x 5.1″)
WEIGHT: 0.5Kg
