PRIS:54 000 kr med media kort

Arcam FMJ A 49 Förstärkare

Sommarkampanj på Arcam ,du får minst 20% i inbyte vid köp av Arcam FMJ A 29, FMJ A 39, FMJ A 49,eller FMJ A 250.





Arcam’s A49 integrated amplifier represents the pinnacle of Arcam’s audio engineering. We set out to incorporate everything we have learnt in almost 40 years to deliver an amplifier that will set new standards and provide class leading sound quality for the best possible reproduction of your music.

Drawing on the many years of amplifier design experience at Arcam, the A49 uses the best quality components and engineering practice to produce a product that will give many years of musical pleasure and reliable service.

With a class G amplifier, toroidal based power supply, acoustically damped chassis, paralleled transistor output stages and exceptionally low levels of distortion and noise the A49 is capable of reproducing music with all its original authority and detail. The A49 features dual mono volume controls and a balanced signal path all the way though the product together with distortion nulling input multiplexers. Rest assured you will be hearing the music just as the artist intended.

The A49 has been designed to leapfrog the competition with a massive 200 watts per channel into 8 ohms and 400 into 4 ohms. It delivers 50 watts in pure class A mode while allowing for huge extra power reserves from our latest generation class G topology that is both clever and efficient. During normal operation, distortion is measured in less than one part per million so that this massive power is deliver with total control and finesse.

There have been great strides made in improving audio sources and loudspeakers in recent years and the time is right to match them in the field of amplifier design. This ground breaking amplifier is a must audition amplifier for music lovers who understand that power is nothing without control.

Technical Specifications

Continuous power output, per channel, 8Ω

Both channels driven, 8Ω,20Hz-20kHz, 0.2% THD – 200W
Single, 4Ω, at 1kHz – 400W
Inputs – Phono (MM) cartridge

Input sensitivity at 1kHz – 5mV
Input impedance – 47kΩ +100pF
Frequency response (ref. RIAA curve) – 20Hz-20kHz +/- 1dB
Signal/noise ratio (Awtd) 50W, ref. 5mV input – 80dB
Overload margin, 5mV at 1kHz – 20dB
Inputs

Nominal sensitivity – 1V (RCA), 2V (XLR)
Input impedance – 10kΩ
Maximum input – 8V (RCA), 15V (XLR)
Frequency response 20Hz-20kHz +/- 0.05dB
Signal/noise ratio (Awtd) 50W, ref 1V/2V input – 105dB
Preamplifier output

Nominal output level – 1.15V (RCA), 2.3V (XLR)
Output impedance – 47Ω (RCA), 200Ω (XLR)
Headphones output

Maximum output level into 600Ω – 4Vrms
Output impedance – 1Ω
Load range – 16Ω-2kΩ
General

Power consumption (standby) – <0.5W
Dimensions & Weights

W x D (inc. speaker terminals) x H (inc. feet) – 433 x 425 x 171mm
Weight (net) – 19.7kg
Weight (packed) – 21.4kg
